Super Multi NX Multi Series - FTXS Wall Mounted Multi-Split Type
Select hp/model
Specifications
Model
Indoor Unit
FTXS60KAVMN
Outdoor Unit
3MXS68LVMA9 / 4MXS80LVMA9
Indoor Unit
Airflow Rate
Cooling: 10 - 16.2 (5 steps) m³/min
Heating: 10.5 - 17.4 (5 steps) m³/min
Dimensions (H x W x D)
290 x 1,050 x 250 mm
Sound Level
Cooling: 33 - 45 dB(A)
Heating: 32 - 44 dB(A)
Weight
12 kg

Remarks

The data are based on the conditions below:
Cooling: indoor temp. 27°CDB/19°CWB; outdoor temp. 35°CDB
Heating: indoor temp. 20°CDB; outdoor temp. 7°CDB/6°CWB
Piping length: 5m

For the selection of model and connection method, please refer to product catalogue.
